$59.99 Each
In stock
Mill your own loose tenon stock for the Beadlock Joinery System!
  • Buy 3 for $46.79 each and save 22%

Rockler Beadlock® Tenon Router Bit - 3/8" Dia x 1-3/4" H x 1/2" Shank

Item #
31318
Rating:
82% of 100

Save money by making your own Beadlock® loose tenon stock - just raid your scrap bin for material. Featuring precision-machined carbide flutes, this bit trims stock to 3/8" widths for a perfect match to your 3/8" Beadlock® mortise. Its sturdy 1/2" shank ensures minimal vibration. You can stock up by running long lengths and cutting off tenons as needed, or you can just run a few short pieces for a small project. With Beadlock® Router Bits, the choice is yours!

  • 1/2" shank for minimal vibration.
  • Approximately 3-1/2" long overall.
  • Carbide length: about 1-3/4".
  • Ultra-fine grade K20 tungsten carbide.
(1) 3/8" Beadlock® Tenon Bit
More Information
Brand Beadlock
Weight 0.4500
Technical Documents
Bit Type Joinery
Diameter 3/8"
Cutter Height 1-3/4"
Shank Size 1/2"
Flutes 2
Prop 65 WarningWARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov

Prop 65 WarningWARNING: Drilling, sawing, sanding or machining wood products can expose you to wood dust, a substance known to the State of California to cause cancer. Avoid inhaling wood dust or use a dust mask or other safeguards for personal protection. For more information go to www.P65Warnings.ca.gov/wood.
4.1 / 5.0
17 Reviews
5 Stars
4 Stars
3 Stars
2 Stars
1 Star
8
6
1
0
2
essential addition if you bought the beadlock kit
I had a bunch of frames to make for my wife's upholstery education business and decided to try the beadlock system over conventional mortice and tenons. So much easier but at 6 joints per frame the bought tenons become expensive quickly. the router bit paid for itself in spades. the frames were 11/2"x 2" so using 2x3 poplar, I was able to use the milled 1/2" offcut to make the tenons. The other advantage over the bought tenons is you can adjust the fit to be tighter or slightly looser by adjusting the thickness at the router table and make custom lengths. Hopefully Rockler will bring out a cutter for the 1/4" and 1/2" beadlock system in the future.
February 25, 2019
Purchased
7 months ago
Woodworking Experience:
Intermediate
Stock Bit
Produces a quality product.
December 16, 2017
Purchased
1 year ago
Like any other it you have to set up the height and fences. I recommend setting up the fence dead on with troughs in it vs the newbie instinct to set up the material to go between it and fence. Also, use featherboards.
December 1, 2017
Purchased
1 year ago
Woodworking Experience:
Intermediate
Great products and service
The shipping took a little long, but the service of Rockler pals is flawless... Received my products in Mexico City and, of course, will repeat the experience.
July 6, 2016
Purchased
over 3 years ago
Woodworking Experience:
Beginner
Great value and service
Excellent router bit. Ordered from the United States as could not get one in the UK. Excellent quality and hassle free transaction, recommended, will use again.
December 22, 2015
Purchased
over 3 years ago
Woodworking Experience:
Intermediate
Cheap as chips
Compared to what I would pay in the Uk this router bit is brillaint value and is high quality.

I couldn't wait to get it into the table, followed an online instruction video and after one foul up I was knocking out tenon stock like a man possessed, this will pay for itself in no time at all at the rate I'm converting scrap timber I'll be selling it at a profit! OK perhaps not......
November 26, 2015
Woodworking Experience:
Intermediate
after minor set up on the router table, the bit produced flawless tenon stock.
August 15, 2015
Purchased
over 4 years ago
Woodworking Experience:
Intermediate
Good buy
If you buy this keep in mind that milling the wood first is a very good idea. I milled the wood down first and using the bit was easy with the use of feather board. You can produce product fast.
October 13, 2014
Woodworking Experience:
Intermediate
works great after some practice
With zero instructions, no videos, no anything, this bit took a round 8 feet of 2 x 2 scrap boards before I got it working for me. Now that I have it dialed in, it's saving me tons of money and shop space as I use scrap wood for my loose tenon joinery
August 9, 2019
Purchased
2 months ago
Woodworking Experience:
Beginner
Works well once you get the hang of it...
This bit works as expected after running through a ton of stock to figure out how it needed to be set up. Evidently, you're supposed to trim your stock to 3/8" thick and align your router table fence with the trough of the "beads" in the bit. It would have been most helpful to have instruction sheet in the package! Maybe then I wouldn't have run through a ton of different widths of hard maple and walnut to get it to cut properly
May 7, 2019
Woodworking Experience:
Intermediate
Start typing your question and we'll check if it was already asked and answered. Learn More
Browse 6 questions Browse 6 questions and 36 answers
Why did you choose this?
Rockler Store
To make my own inserts
Les B on Sep 12, 2019
Go tthis because they didn't offer the bit for 1/2" stock
James R on Jul 18, 2019
To make my own inserts
Les B on Sep 12, 2019
Seems like it would be easy to make this if you have a router table
chris p on Jul 23, 2019
Go tthis because they didn't offer the bit for 1/2" stock
James R on Jul 18, 2019
Hoping it will pay for itself after not too many projects.
L. A on May 8, 2019
I like the ability to make my own stock
Rosario D on Apr 22, 2019
To make more dowels
Paul B on Jan 13, 2019
gift
Richard P on Nov 23, 2018
I want to make my own Tenon's for custom hard wood work
Tirchian R on Nov 9, 2018
I want to make my own Beadlock stock.
Paul on Aug 7, 2018
Gift for my husband
Raelyn D on May 22, 2018
I see in you tube video. its good tool
Jesus Z on Apr 17, 2018
This company has excellent products and its tools provide perfect solutions to our jobs
To make my own tenons and save money.
Alexander L on Sep 18, 2017
make my own tenon stock to save money
kelly L on Nov 30, 2016
Down the road this will be more cost affective while allowing me the option of choosing the strength of my tennon materials.
Neil F on Oct 10, 2016
I am building a table and this looked to be a great joinery system.
David L on Sep 18, 2016
Makes sense to make my own beadlock stock vs buying it.
Kurt B on Aug 14, 2016
Make my own tenons
Aaron S on Jul 28, 2016
hoping to make my own tenons using scrap hardwood
John M on Dec 13, 2015
I have the beadlock pro kit and the tenon router cutter extends it use, enabling me to cut my own tenons rather than hunting on the net to purchase ready cut stock.
Christopher W on Oct 3, 2015
I am looking to expand ways to join woodwork.
stephen t on Jul 5, 2015
I bought the Beadlock 3/8" kit from Rutlands in the UK and was shocked when I discovered the price of the tenon stock so decided to make my own. I could not find anyone in the UK with the correct router bit so bought this one from Rockler.
Brian H on Jun 24, 2015
needed with other tool orderd
melvin h on May 29, 2015
to make my own tenons
james j on May 22, 2015
Seems like it would be easy to make this if you have a router table
chris p on Jul 23, 2019
Hoping it will pay for itself after not too many projects.
L. A on May 8, 2019
Will the 1/4" and 1/2" versions of the Beadlock router bits be made available?
Jim_Day on Dec 11, 2016
BEST ANSWER: Sorry no, only the pre-made tenon stock is available for the 1/4" and 1/2" sizes.
What are the instructions for making tenons with this bit?
CHARLES B on May 6, 2017
BEST ANSWER: Mill your stock to 3/8" and the proper height (~1-3/4") of the cutter, then run it through the cutter on both sides. You might need to do a few tests to make sure that you have the right stock thickness to end up with the correct bead thickness. You want to use a featherboard to keep the wood tight to the cutter, and best to mill a number of pieces all at once. Overall, it's a very easy process.
What guide do I use to drill the holes for tenons this bit makes or do I just use a drill press without a guide?
Louis W on Apr 5, 2017
BEST ANSWER: I used the Beadlock Pro as the guide. The Pro has a clamp that enables you to accurately position the guide.
I believe it would be quite difficult to manually drill the 3/8 holes for the tenon it produces as they overlap!
Initially I found it really difficult to use the carbide bit until I saw a technique that I found on Utube.
Good luck.
Is it possible to cut stock without a router table?
Matt H on Aug 13, 2015
BEST ANSWER: no, and you really need to use a featherboard on the table as well to ensure even thickness.
does this bit work for the 1/4 and 1/2 tenons as well?
Jeremy A on Jun 27, 2015
BEST ANSWER: To the best of my knowledge each bit is unique where the radius of the flutes match the radius of the drill being used - as such you will need other router bits matched to 1/4" and 1/2" tenon sizes
